| Items |
Specification Details |
| PC System (Customizable) |
| Motherboard |
Advantech/ Seavo/ Gigabyte |
| CPU |
Intel G2030/I3/ I5 /I7 |
| RAM |
2GB/4GB/8GB |
| HDD/SSD |
320GB/500GB; 64GB |
| Power Supply |
Hunt Key/Great Wall |
| Interface |
RS-232 Ports; LTP; USB Ports, 10/100/1000M |
|
| Touch Screen |
| Screen Size |
17”, 19” (optional from 15” to 22”) |
| Screen Type |
SAW, IR, Capacitive |
| Resolution |
4096x4096 |
| Feature |
High Transparence, Precision and Durability |
|
| Monitor |
| Screen Size |
(optional from 21” to 55”) |
| Brightness |
300cd/m2 |
| Contrast |
1000:1 |
| Resolution |
1280x1024(1920*1080) |
|
| Kiosk Cabinet |
| Material |
Cold-rolled Steel ST12 SPCC with1.5mm thickness |
| Coating |
Car painting technology |
| Feature |
Easy service access through front and back |
| Color or Logo |
Customizable |
| Parts |
*Independent power supply *Multimedia speakers *Internal ventilation system |
|
| Card Reader |
| Card Type |
Magnetic card, IC Card, RF Card, Chip Card |
| Interface |
RS232/USB |
| Card Entry Method |
Signal of Magnetic, Optoelectronic and rear card |
|
| Encrypted Pin Pad |
| Key Life Span |
2,000,000 cycles |
| Key Force |
2-3N |
| Key Trip |
>2.5mm |
| Protection Level |
IP65 |
|
| Thermal Printer |
| Brand |
Epson/Custom/Citizen |
| Auto-cutter |
Included |
| Width of Paper |
58mm/80mm/112mm |
| Printing Speed |
150mm/s |
| Buffer of Data |
4Kb |
| Interface |
RS232/USB |
|
| Operation System |
Windows 2000/ Windows XP/ Windows 7/ Windows 8/ Linux
|
| Power Supply |
| AC Input Voltage |
100~240V/AC |
| Frequency |
50Hz to 60Hz |
|
|
Other Peripheral
|
UPS, Wi-Fi, Web-camera, LAN port, USB port, Scanner and etc
|
